HY95C Forestry Machinery

Key Highlight Features

1. Power System: Isuzu 4JG3X engine with 55kW rated power, high torque output, ECU precise fuel injection for better fuel economy.
2. Hydraulic Upgrade: 22mm large bore main valve, electric control arm technology, low pressure loss to cut comprehensive energy consumption.
3. Reinforced Structure: Thickened long reinforcing plates on arm, strengthened boom frame, rectangular tube dozer blade, enhanced track guard for longer service life.
4. Premium Cabin: 7-inch smart touch display with Bluetooth, USB, radio; optimized air duct, multi-function one-button start, 12V power & cup holder.
5. Strong Passability: Dozer blade lifting height raised by 70mm, lifting angle +5°, stable support on soft ground.

Performance Advantages

1. Powerful Digging Capacity: Bucket digging force 63.6kN, arm digging force 46.8kN, maximum torque 280N·m, easily break hard soil and stone piles.
2. Excellent Off-road Performance: 70% climbing capacity (35°), dual travel speed 5.0/2.9km/h, stable 38.6kPa ground pressure to avoid sinking on muddy farmland.
3. High Working Efficiency: 11rpm smooth swing speed, matched large-flow hydraulic system, fast compound action for trenching and backfilling.
4. Low Operation Cost: Precise electric fuel control reduces fuel waste; reinforced structural parts lower frequent replacement and maintenance fees.
5. Intelligent Control: 7-inch screen monitors real-time machine status, adjustable air conditioner, easy media switching to reduce operator fatigue.

Technical Specification

Overall Weight: 9180kg | Standard Bucket Capacity: 0.38m³

Engine Model: Isuzu 4JG3X | Rated Power: 55kW/2000rpm | Max Torque: 280N·m/1800rpm | Displacement: 2.999L

Working Performance: Climbing 70%(35°), Swing Speed 11rpm, Ground Pressure 38.6kPa

Digging Force: Bucket 63.6kN, Arm 46.8kN | Travel Speed: 5.0/2.9km/h

Undercarriage: 450mm standard track shoe, 5 support rollers, 1 top roller per side, 41 track links

Fluid Capacity: Fuel Tank 160L, Hydraulic Tank 120L, Engine Oil 13.2L, Radiator 12L, Final Drive 2×1.2L

Hiyo HY95C 9-ton compact excavator stands out as a versatile mini digger for municipal and agricultural projects, fully meeting National IV emission standards. Powered by reliable Isuzu 4JG3X engine with 55kW power output, it balances high torque and low fuel consumption perfectly. The upgraded large-bore hydraulic main valve optimizes oil flow, cutting energy loss while boosting digging efficiency. Reinforced boom, arm and dozer blade extend service life for frequent trenching, leveling and backfilling work. Equipped with a 7-inch intelligent display, operators can check machine data, play music and adjust cabin temperature easily. Its 38.6kPa low ground pressure prevents sinking on soft farmland, and 70% climbing ability handles uneven rural roads. With a 0.38m³ bucket and powerful digging force, it completes small earthmoving tasks quickly. Ideal for town reconstruction, landscaping, irrigation ditches and house foundation jobs, HY95C lowers maintenance costs and brings stable long-term returns for small contractors.

Independent R&D Team Optimizes HY95C Power & Hydraulic Technology

Hiyo owns a large independent R&D center focusing on small earthmoving machinery, with professional engineers specialized in power matching, hydraulic system and structural reinforcement. The HY95C mini excavator is fully optimized through thousands of working condition simulation tests. R&D team matched Isuzu engine with large-flow low-loss hydraulic main valve, innovating arm electric control and differential pressure auxiliary technology to cut energy consumption. They redesigned boom, arm and dozer blade structures based on real construction feedback, enhancing impact resistance and rigidity. Cabin intelligent system, 7-inch touch display and optimized air conditioning are all self-developed matching schemes. Continuous technical iteration upgrades HY95C efficiency and durability, keeping Hiyo small excavators competitive in the global machinery market.
