HYM5465THBF 620S-62Meters Mini Mixed Concrete Pump

Key Highlight Features

1. Full electric auxiliary MHEV layout: lithium iron phosphate battery, multi-in-one controller, electric mixing motor, electric water pump, electric radiator and integrated generator control system.
2. Big cost-saving design: 12%-15% total energy reduction, annual fuel, urea and maintenance cost cut by 37,000-47,000 RMB for 55,000 cubic meters annual pumping.
3. Intelligent electric mixing system: auto engine stop under waiting mode, remote one-click start-stop, constant-speed stirring, electric-hydraulic dual drive to avoid concrete segregation.
4. Low-noise electric washing pump: 11MPa high pressure, 15.7m³/h flow, only 2 kWh power consumption for 30 mins cleaning without hydraulic oil waste.
5. DC 24V inverter parking air conditioner: 2000W cooling capacity, 37dB low inner noise, only 1 kWh per hour, low voltage protection for safe parking cooling.
6. Triple charging solutions: fast DC charging ≤1h, self-charging while driving, optional household slow charging for flexible power supply.
7. Full intelligent monitoring: visualized electric parts data, automatic electric/hydraulic switching, real-time running statistics and auto fault diagnosis & protection.
8. 7-section long boom: 61.1m vertical reach, ±360° turntable rotation, stable pumping for high-rise and deep foundation projects.

 Performance Advantages

1. Outstanding Energy Saving Advantage: MHEV quantitative power output eliminates idle fuel waste. Waiting material stage saves 87% energy vs traditional diesel pump truck; washing and air conditioning cut energy loss by over 95%. Annual fuel cost drops 314,600 RMB, plus extra 2,000 RMB urea & maintenance savings.
2. Superior Pumping Stability: 7-section optimized boom with anti-vibration design, dual electric-hydraulic mixing ensures uniform concrete mixing without segregation; low/high pressure dual pumping mode covers different construction height demands.
3. All-scene Comfort Upgrade: Electric washing and parking AC remove high fuel consumption and loud engine noise during stationary work, greatly improving operator working environment.
4. Flexible & Reliable Power Supply: Three charging modes adapt to construction sites without fixed industrial power; 6-hour pure electric mixing endurance meets all-day waiting operation.
5. Low Maintenance Cost: Less hydraulic pipeline layout on electric auxiliary system reduces oil leakage risk; intelligent fault alert cuts unexpected downtime and repair frequency.
6. Wide Working Coverage: 61.1m vertical height, 54.4m horizontal reach, 43.2m vertical depth, minimum unfolding height only 15.8m, fits narrow municipal sites and super high-rise buildings.
7. National VI Emission Standard Hiyo Chassis: D13C6-480E0 engine delivers 348kW power, max speed 90km/h, meets global mainstream construction emission regulations.

Technical Specification

Model: HYM5465THBF 620S-MHEV

Axle: 4 axles; Hiyo self-developed chassis; Gross weight: 46000kg

Overall dimension: L14720 × W2550 × H4000mm

Boom data: Vertical height 61.1m, horizontal reach 54.4m, vertical depth 43.2+3m hose, min unfold height 15.8m, 7-section boom, turntable ±360° rotation

Pumping system: Low pressure output 180m³/h, high pressure 125m³/h; low pressure 8.3MPa, high pressure 13MPa; open hydraulic system, max system pressure 32MPa

Power battery: 30kWh lithium iron phosphate battery; DC fast charging ≤1h; 6h pure electric mixing endurance

Electric auxiliary parts: Electric water pump 11MPa/15.7m³/h; DC 24V parking AC, cooling capacity 2000W

Engine: D13C6-480E0, 348kW/1900rpm, National VI emission, fuel tank 600L

Tank volume: Hydraulic tank 450+450L, water tank 700+700L

Delivery pipe: 125mm diameter, 3m end hose

Wide Application & Reliable Hybrid Performance

Hiyo 620S-MHEV 62-meter hybrid concrete pump truck delivers universal pumping performance across multiple construction sectors, favored by medium and large construction enterprises globally. The 7-section boom reaches 61.1m vertical height and 54.4m horizontal length, with flexible unfolding posture suitable for narrow municipal roads, super high-rise residential buildings, long-span bridges and deep tunnel projects.

It also fits water conservancy, stone quarry, pipeline and energy facility construction, with dual high-low pressure pumping modes to match thin or thick concrete materials. The MHEV hybrid structure combines diesel engine and electric power to guarantee stable pumping output even under heavy continuous working loads.

Three charging options remove site power restrictions, while intelligent self-diagnosis system monitors all electric modules to cut unexpected downtime. Compared with traditional diesel pump trucks, it slashes fuel, urea and maintenance cost year by year. National VI emission standard meets global environmental regulations, and Hiyo self-developed 4-axle chassis ensures long-term driving reliability. For contractors needing multi-scene, energy-saving pumping equipment, this 62m MHEV boom pump provides maximum long-term economic benefits.
