Product Overview：

The Hiyo HW956E-MAX is a 5.8-ton all-round electric wheel loader engineered for medium and heavy-duty industrial operations. With an operating weight of 19,000kg and a standard 3.5m³ bucket (adjustable from 2.7–5.0m³), it delivers stable 5,800kg rated load capacity. Two battery options (282kWh / 350kWh) support long-hour continuous work, built with full IP67 three-electric system protection and intelligent thermal management to operate steadily from -35°C to 60°C. Adopting regenerative braking and auto-idle energy-saving tech, this zero-emission loader cuts operating costs greatly, perfectly matching steel plants, mines, ports, coal yards and mixing stations for bulk material loading, hauling and stockpiling. Hiyo’s independent two-speed transmission, low-vibration luxury cab and one-touch intelligent control bring operators high efficiency, safety and comfort in all weather conditions.

Key Highlight Features：

1. Safe High-Capacity Battery: Compliant with GB38031, no fire or explosion under collision/extrusion, full battery safety protection.
2. High-Efficiency Drive Motor: 95% max efficiency, peak torque 3200N·m, IP67 waterproof/dustproof for rain and wading work.
3. Dual Energy-Saving Tech: Regenerative braking reduces power consumption by 18%; intelligent auto-stop cuts idle loss by 5%.
4. All-Climate Fast Charging: Compatible with all DC charging piles, max 400A dual-gun charging, full charge within 1 hour with 320kW charger.
5. Brake Priority Safety Logic: Avoid misoperation wear and unexpected accidents when braking.
6. Premium Operator Cab: 10% better sealing than fuel loaders, 68dB low noise, 30% less vibration, full panoramic view, integrated touch intelligent control.
7. Smart Thermal Management: Liquid cooling battery system with PID algorithm, automatic cooling & self-circulation for energy saving.Performance Advantages：

   The HW956E-MAX outperforms traditional fuel wheel loaders in power, energy efficiency and environmental adaptability. It generates 180kN maximum traction force and 182kN breakout force with only 10.5s total three-action cycle, delivering faster loading cycles and higher site throughput. The independent two-speed transmission enables smooth, aggressive direction shifting without power lag. The electric system

   eliminates exhaust pollution and lowers daily fuel and maintenance costs significantly. It works reliably under -30°C to 50°C ambient temperatures with dedicated air conditioning, while the intelligent control system simplifies operation with one-key start, shift and real-time machine data monitoring. The whole machine structure is heavy-duty reinforced for long-term continuous heavy loading in mining and quarry stone projects.

   Technical Specification：

   1. Basic Performance

   Rated Load: 5800kg | Operating Weight: 19000kg | Standard Bucket Capacity: 3.5m³ (2.7–5.0m³ optional)

   Dump Height: 3345mm | Dump Reach: 1220mm | Max Traction Force: 180kN | Max Breakout Force: 182kN

   Total Three-Action Time: 10.5s

   2. Power & Battery

   Battery Capacity: 282kWh / 350kWh optional | Motor Peak Torque: 3200N·m | Max Motor Efficiency: 95%

   Working Temp Range: -35°C ~ 60°C | Max Charging Current: 400A Dual Gun

   Charging Time: 282kWh≈60–70min (240–320kW pile); 350kWh≈85–95min

   3. Machine Dimension

   Length: 8560mm | Width: 2845mm | Height: 3560mm | Wheelbase: 3400mm

   4. Protection & EnvironmentThree-Electric Protection Grade: IP67 | Cab Noise: 68dB | Vibration Reduction: 30% vs fuel loaders

      Article 1 Energy Saving & Low Operation Cost Focus：

      Hiyo HW956E-MAX electric wheel loader stands as a cost-effective zero-emission replacement for heavy fuel loaders in industrial bulk material handling. Designed for 5.8-ton rated load, this model offers dual battery packs (282kWh and 350kWh) to satisfy short-shift and round-the-clock production lines. Its core competitive edge lies in dual energy-saving innovations: regenerative braking converts kinetic energy into stored power to cut power consumption by 18%, while intelligent auto-stop eliminates idle power loss for another 5% energy reduction. Compatible with all mainstream DC

      charging piles, dual-gun 400A fast charging shortens downtime greatly. The IP67 sealed motor and battery system work normally under -35°C to 60°C, suitable for coal yards, steel mills and mixing stations. Compared with diesel loaders, it removes fuel expense and reduces daily maintenance workload. Equipped with a low-noise, low-vibration luxury cab and integrated touch control, operators enjoy long-hour fatigue-free work. With 180kN traction and 182kN breakout force, it matches all heavy-duty stone and mineral loading tasks without sacrificing production efficiency.

      Article 2 Safety & Intelligent Operation Focus：

      Safety and intelligent operation are core highlights of Hiyo HW956E-MAX electric wheel loader, built for high-risk industrial sites including mines and ports. The battery pack meets national GB38031 safety standards, resisting fire and explosion under collision or extrusion impacts to fully protect operators. A unique brake priority function cuts power output automatically during braking to prevent wear and misoperation accidents, adding an extra safety layer. All three-electric core components reach IP67 protection grade, supporting rain, snow and shallow wading construction without breakdowns. Inside the cab, panoramic large glass delivers wide sight, noise controlled at only 68dB and vibration reduced by 30% vs fuel machines. One-touch start, one-key shift and real-time machine data screen simplify complicated operation steps. Intelligent battery liquid cooling thermal management uses PID algorithm to adjust temperature accurately, avoiding overheating or overcooling. The independent two-speed transmission brings smooth shifting and fast response. With 10.5-second full work cycle and adjustable bucket capacity, it balances safety, intelligence and high productivity for quarry, power plant and logistics yard use.

      Article 3 All-Weather & Heavy-Duty Performance Focus：

      Hiyo HW956E-MAX 5.8-ton electric wheel loader is engineered for all-weather heavy-duty continuous operation, capable of stable work in extreme cold and hot environments from -35°C to 60°C. Equipped with a heavy-duty reinforced body, it delivers 180kN maximum traction and 182kN breakout force, perfectly handling stone quarrying, aggregate production and coal bulk transportation. The optional 2.7–5.0m³ bucket covers light to super-heavy loading demands, while two battery capacities (282kWh / 350kWh) support flexible shift arrangements. International brand thermal management components ensure stable battery temperature under extreme climate, paired with powerful cab heating and cooling air conditioning. Fast charging compatibility shortens waiting time: a 320kW charger fills 282kWh batteries within 60 minutes. IP67 dust and water resistance allows outdoor year-round work without seasonal limitations. Zero exhaust emission satisfies global environmental policies for steel plants and ports. Hiyo’s mature electric drive technology cuts failure rates, lowering long-term site operation costs, making this model a reliable long-term investment for medium and heavy material loading projects worldwide.

      Title: Hiyo Global Manufacturing Strength for Electric Construction：

      As a world-leading construction machinery brand, Hiyo has built standardized intelligent manufacturing bases for electric wheel loaders. Every HW956E-MAX loader undergoes strict offline testing before delivery to match global industrial standards. We integrate self-developed three-electric systems, independent transmission and intelligent control modules in-house, cutting reliance on external core parts. Global after-sales service networks cover mining, port and steel plant clients with fast spare parts supply and on-site technical support. Our factory implements full production quality tracking, each machine with unique serial numbers for full lifecycle monitoring. Focusing on green machinery development, Hiyo launches high-efficiency electric loaders to help global clients lower carbon emissions and operational costs. All products pass GB38031 safety certification and IP67 protection tests, meeting multi-country construction equipment entry requirements.

      Title: Advanced Workshop Production Process of Hiyo Electric Wheel：

      Hiyo’s electric loader intelligent workshop adopts automated welding, robotic assembly and digital quality inspection lines for HW956E-MAX production. The battery assembly workshop operates in dust-free constant-temperature environments to guarantee battery safety and stability. All three-electric components go through waterproof, impact and high-low temperature aging tests before assembly. Heavy-duty structural parts use high-strength steel with automatic welding to enhance machine durability under long heavy loads. Digital MES systems record every production procedure for quality control. Compared with traditional production lines, our automated workshop improves assembly precision and shortens delivery cycles. Each finished HW956E-MAX completes full load, charging and road test before packaging, eliminating hidden faults for end users in mining and mixing station projects.

      Title: Independent R&D Team Behind Hiyo HW956E-MAX Electric Loader

      Hiyo owns a large professional new energy construction machinery R&D team focusing on electric wheel loader core technology breakthroughs. The HW956E-MAX integrates multiple self-developed patents including regenerative braking energy recovery, intelligent battery thermal management and two-speed electric transmission. Our R&D lab simulates -35°C to 60°C extreme working conditions to optimize battery, motor and control system performance. Engineers solve pain points of high power consumption, poor low-temperature charging and low operator comfort of traditional electric loaders. Continuous technical iteration lowers power consumption by 23% total via dual energy-saving tech. All intelligent control logic, brake priority safety program andcharging matching algorithms are self-designed, ensuring core technical independence and reliable after-sales technical upgrade support for global clients.

       Title: Hiyo Core Development Concept: Quality Changes the World：

      “Quality Changes the World” is Hiyo’s permanent brand development concept, fully reflected in the HW956E-MAX electric wheel loader. We prioritize user safety, low operation cost and long service life in all product design links. All material selection, structural design and three-electric matching target medium-heavy industrial users’ real site demands. We refuse low-cost inferior accessories to avoid frequent breakdowns on mines and ports. Green low-carbon development is another core concept: all electric loaders realize zero tailpipe emissions to help global construction industries achieve carbon neutral goals. Humanized cab design, simple intelligent operation and all-scenario adaptability are designed to reduce operator fatigue and raise site efficiency. Hiyo balances quality, environmental protection and user value in every equipment.

      Title: Large-Scale Global Supply Capacity of Hiyo Electric Loaders：

      Hiyo boasts large-scale intelligent manufacturing capacity to supply mass HW956E-MAX electric wheel loaders for global markets. Multiple production lines run simultaneously to guarantee fast delivery for bulk orders from steel plants, quarries and port logistics companies. We establish stable upstream supply chains for high-capacity batteries, drive motors and transmission assemblies to avoid production delays. Regional overseas warehouses stock finished machines and spare parts for quick local delivery in Asia, Europe and Oceania. Annual production capacity of electric wheel loaders reaches thousands of units, supporting large infrastructure and mineral development projects worldwide. Standardized packaging and global logistics systems ensure intact machine transportation across long distances, offering stable, large-volume green loading equipment supply for international industrial clients.Steel Plant Worksit：

      HW956E-MAX electric loader handles steel slag, raw material stacking and furnace feeding inside steel plants. Zero exhaust avoids workshop pollution; low noise meets indoor operation requirements, IP67 parts resist dust and high-temperature dust environment.

      Mining & Quarry Aggregate：

      Suits stone excavation, rock loading and aggregate material transportation. High traction & breakout force cope with heavy stone loads; dual battery options support long continuous quarry shifts.

      Coal Yard & Thermal Power Plant：

      Load and pile bulk coal, clean coal residue. Dustproof IP67 three-electric system prevents coal dust damage; energy-saving tech cuts power cost for daily mass coal handling.

      Concrete Mixing Station：

      ansport sand, stone and cement raw materials inside mixing stations. Low vibration & quiet cab create comfortable indoor operation; adjustable bucket capacity fits different raw material volumes.

      Port & Logistics Yard：

      Bulk cargo stacking, container yard material hauling. Fast dual-gun charging reduces downtime; wide working temperature range adapts coastal humid and high-salt environments.

      General Earthwork & Municipal Logistics：

      Small earthwork backfilling, construction waste moving and factory material transfer. Zero emission complies with urban environmental limits; intelligent control lowers operation difficulty for new drivers.
