HY240 Hydraulic Excavator

Product Overview

Hiyo HY240 hydraulic excavator adopts 129kW Weichai engine, cutting fuel consumption by 15%. Optimized hydraulic and structural systems boost digging force by 15% with 1.3-1.5m³ wear-resistant bucket. It features smart touch cab and stable, durable body for efficient construction.

1. Key Highlights

• High productivity & powerful digging capacity for heavy-duty tasks
• 15% lower fuel consumption compared with same-class excavators
• Upgraded large-flow hydraulic system with optimized flow distribution
• Luxury intelligent panoramic cab with full humanized configurations
• Robust large-capacity components supporting long-hour continuous operation

2. Performance Advantages

① Powerful Engine

• Model: WP7HG175E440
• Type: Inline 6-cylinder four-stroke engine
• Rated power: 129 kW @ 2000 rpm
• Displacement: 6.8 L
• Stable power output, reliable performance and convenient daily maintenance

② Upgraded Hydraulic System

• Main pump: FMP130APDTPR
• Rated system pressure: 34.3 MPa
• Max pump flow: 300 L/min
• Optimized flow distribution via big data calculation
• Fast response, smooth compound movements and high overall construction efficiency

③ Optimized Structure & Heavy-Duty Durability

• Big data optimized structural stress distribution to eliminate internal stress
• Digging force increased by 15% through redesigned working attachments
• Patented wear-resistant bucket, bucket capacity boosted by 20% vs peer models
• Standard bucket capacity: 1.3–1.5 m³
• Reinforced boom & arm with stable load transmission and long service life

④ Intelligent Luxury Comfort Cab

• Multi-functional touch screen (Bluetooth, A/C, USB, telephone, radio)
• Ergonomic air-suspended shock-absorbing adjustable seat
• Keyless one-button start system
• Built-in cup holder & high-bright LED overhead reading light
• Wide panoramic vision to reduce blind zones and improve operation safety

⑤ Easy Maintenance & Reliable Mobility

• Large-opening side doors and engine hood for simple inspection and maintenance
• Two-speed travel mode: 5.5/3.4 km/h
• Wide 600mm standard track shoes for stable driving on soft ground
• Large radiator to keep stable hydraulic oil temperature under all weather conditions

Complete Machine Technical Specifications

Category	Item	Unit	HY240 Specification
Basic Specifications	Product Model	/	HY240
	Operating Weight	kg	23500
	Standard Bucket Capacity	m³	1.3–1.5
Main Performance	Travel Speed (High/Low)	km/h	5.5/3.4
	Bucket Digging Force	kN	145
	Arm Digging Force	kN	120
Engine	Model	/	WP7HG175E440
	Type	/	Inline 6-cylinder four-stroke engine
	Number of Cylinders	pcs	6
	Rated Power	kW/rpm	129/2000
	Displacement	L	6.8
Hydraulic System	Main Pump Model	/	FMP130APDTPR
	Rated System Pressure	MPa	34.3
	Max Flow	L/min	300
Fluid Capacities	Hydraulic Oil Tank Capacity	L	210
Travel System	Number of Track Shoes	pcs	47
